Product Description
The WATCHPAX 62 series (62S / 62A / 62B / 62C) comprises four performance-optimized models from the lean four-output model S to the high-end model C with up to twelve outputs. Sleek, robust and with a compact 2U form factor, WATCHPAX 62 is the successor to the popular WATCHPAX 60 series. This new generation combines the same elegant exterior with a fully updated tech spec to pack an even more powerful punch!
Features
All models
- WATCHOUT license (built-in)
- Four 4K DisplayPort outputs
- Four USB (2 x 2.0, 2 x 3.2) ports
- Two 10 Gb/s network ports*
Model S
- 1.9 TB high-performance SSD
Models A, B, C
- 3.8 TB high-performance SSD
- SSD options: 7.6, 15.3 TB
- Two HDMI 2.0 inputs (up to 4K capture)
- Audio: Two-channels in, two-channels out, analog or digital**
- XLR** SMPTE timecode input
Model B, C
- Hardware synchronization
Model C only
- Eight-channel bi-directional SDI
In the venue
- Tabletop, rack-mount, stackable
- Smart auto-reset solution
- Locked-down unit
- Kensington security slot to discourage theft
- Rack mount kit available separately
- User-replaceable air filter
Footprint
- Unit dimensions: w 446 mm (17.6 in), h 88 mm (3.5 in), d 336 mm (13.2 in)
- Weight, 10 kg (approx. 22 lbs)
- Rugged, quality aluminum housing
