Product Description
The ET-DLE020G features a sophisticated "L-shaped" mirrorless design that achieves an industry-leading throw ratio of 0.280–0.299:1 (WUXGA). It is the world’s first UST lens for 1-Chip DLP™ systems to incorporate a motorized 1.07x optical zoom, providing a critical adjustment margin of +45mm without physically moving the projector.
Designed for high-reliability 24/7 operation, the lens utilizes an aspherical all-glass construction that is heat- and scratch-resistant. It supports Zero-Offset projection, allowing the image to align perfectly with the lens center—eliminating the vertical gap typically found in standard short-throw setups.
Note: ET-DLE020G is intended for the RQ7 Series.
Superior Flexibility for Easy Installation
Conventional ultra-short-throw lenses demand accurate, time-consuming projector installation positioning with no margin for error. The ET-DLE020’s optical zoom, however, provides an installation margin of ±45 mm (±1.77˝) and easy image adjustment at a throw-ratio of 0.280–0.299:1 (WUXGA, 16:10), all with zero image offset. It combines with Panasonic laser projectors*1 to support Wide-range Vertical and Horizontal Lens-Shift, more than doubling movable shift area of comparable lenses, increasing installation flexibility, and expediting setup.
*1 Please refer to the specifications page to check projectors compatible with ET-DLE020/DLE020G.
*2 Value is for ceiling installations at WUXGA resolution. Lens-shift value will vary by model.
High Reliability for Continuous Operation
The ET-DLE020 features an aspherical all-glass lens that’s heat- and scratch-resistant. Durable construction enhances reliability for long-term use, and when combined with our dust-resistant laser projectors*, assures consistently brilliant images under continuous operation.
* Please refer to the specifications page to check projectors compatible with ET-DLE020/DLE020G.
On-Axis Rear Projection
The ET-DLE020’s straight mirrorless design makes screen-centered projector installation possible in rear-projection applications.
Note: Hot spots may occur depending on the screen.
Zero Offset and Flexible Setup for Multi-Screen Projection
Install your Panasonic 1-Chip DLP™ laser projector on-ceiling and close to the wall for full top-to-bottom screen coverage with zero offset and minimal shadowing, even in low-ceiling applications. Zoom and wide-range V/H Lens Shift joins flexible edge-blending adjustment for multi-screen projection.
| Lens type | Ultra-Short-Throw Zoom Lens |
|---|---|
| F-number | 2.0 |
| Focal length (f) | 4.1–4.4 mm (5/32–11/64 inches) |
| Screen size | 100–400 inches |
| Throw ratio | |
| 4K (16:9) | 0.279–0.297:1 |
| WUXGA (16:10) | 0.280–0.299:1 |
| WXGA (16:10) | 0.294–0.314:1 |
| XGA (16:10) | 0.290–0.309:1 |
| Lens-shift*1 | |
| Vertical | +50 % – -16 % |
| Horizontal | +10 % – -20 % |
| Zoom | Yes |
| Dimensions (W x H x D) | 170 x 170 x 391 mm (6 11/16˝ x 6 11/16˝ x 15 13/32˝) |
| Weight | Approx. 3.2 kg (7.05 lbs) |
| Applicable projectors*2 | PT-RQ7L / PT-RQ6L / PT-RZ7L / PT-RZ6L / PT-RZ990 / PT-RZ890 / PT-RZ790 / PT-RZ690 / PT-RCQ10 / PT-RCQ80 / PT-RZ120 / PT-RZ970 / PT-RW930 / PT-RX110 / PT-RZ870 / PT-RZ770 / PT-RW730 / PT-RZ660 / PT-RW620 |
