Specifications
|
| Projector type |
1-Chip DLP™ projector |
| Light output |
15,000 lm/15,500 lm (Center) |
| Resolution |
4K (3840x2400 pixels) (Quad Pixel Drive: ON) |
| Contrast ratio |
25,000:1 (Full On/Full Off, Dynamic Contrast) |
| Refresh Rate |
240 Hz Refresh rate varies depending on scanning frequency |
| Terminals |
2 x HDMI In
1 x Display Port In
1 x LAN: RJ-45
1 x RS232: DB-9pin (Serial In)
1 x RS232: DB-9pin (Serial Out)
1 x RS232: DB-9pin (Remote In)
1 x USB (DC Out)
1 x USB (for AJ-WM50 Series)
1 x Mini Jacks (Remote In)
1 x Mini Jacks (Remote Out)
1 x BNC In(Multi Projector Sync)
1 x BNC Out(Multi Projector Sync)
1 x Available Slots for Interface Boards |
| Dimensions (W x H x D) |
Approx. 498 x 212 x 538 mm (excluding protrusions) |
| Weight |
28.7 kg |
| Operation noise |
42 dB (NORMAL/ECO), 38 dB (QUIET) |
| Power Consumption |
1,140 W (11.5–4.7 A) (1,150 VA)
(Power consumption is 1,090 W at AC 200–240 V) |
| Supplied Accessories |
Power cord*10, Lens hole cover x 1 , Wireless/wired remote control unit x 1, Batteries for remote control (AA/R6 type x 2), Lens fixing screw x 1 |
Optional Accessories
|
| Lens |
Zoom lens |
ET-C1U100 (0.308-0.330:1) |
| Lens |
Zoom lens |
ET-C1U200 (0.380:1) |
| Lens |
Zoom lens |
ET-C1W300 (0.550-0.690:1) |
| Lens |
Zoom lens |
ET-C1W400 (0.680-0.950:1) |
| Lens |
Zoom lens |
ET-C1W500 (0.940-1.39:1) |
| Lens |
Zoom lens |
ET-C1S600 (1.36-2.10:1)
Note: This product is equivalent to the lens attached to the projector model with standard zoom lens |
| Lens |
Zoom lens |
ET-C1T700 (2.07-3.38:1) |
| Lens |
Zoom lens |
ET-C1T800 (3.3-6.6:1) |
| Ceiling Mount Bracket |
with 6-axis adjustment for high ceilings |
ET-PKD130H |
| Ceiling Mount Bracket |
for high ceilings |
ET-PKD120H |
| Ceiling Mount Bracket |
for low ceiling |
ET-PKD120S |
| Attachment for Ceiling Mount Bracket |
ET-PKD130B |
| Function Board |
12G-SDI Terminal Board |
TY-SB01QS |
| Function Board |
12G-SDI Optical Function Board |
TY-SB01FB |
| Function Board |
DIGITAL LINK Terminal Board |
TY-SB01DL |
| Function Board |
Wireless Presentation System Receiver Board |
TY-SB01WP |
| DIGITAL LINK Switcher |
ET-YFB200G |
| Digital Interface Box |
ET-YFB100G |
| Wire |
