Product Description
Three way passive, symmetrical configuration
The new Aliseo loudspeaker system is the new challenge that Pequod has undertaken, designing an elegant system in composite material using the highest quality and specialized 5 “units. The system has an horizontal, symmetrical, and extremely compact design in relation to the performance. TYPE 3 way passive ,symmetrical configuration FREQUENCY RESPONSE 50 Hz - 18 KHz (-3dB) TOTAL SENSITIVITY 92 dB 1W/1m with passive crossover SPL MAX 114 dB with 300 W LOW FREQUENCY 2x5” woofer @8Ohm 200W continuous power handling each, sensivity 90.5 dB 1W/1m MEDIUM FREQUENCY 5” mid-woofer @ 8 Ohm 300W continuous power handling , sensivity 92 dB 1W/1m HIGH FREQUENCY HF compression driver with high tech polymer diaphragm @ 8 Ohm 50W continuous power handling , sensivity 105dB 1W/1m NOMINAL IMPEDANCE 4 Ohm with 3 way passive crossover POWER HANDLING 350W @ 4 Ohm with amplifier MANAGE 2 Ch amplifier to a couple of Aliseo loudspeakers (passive crossover provided, for each Aliseo). If very high output is needed we recommend to use a DSP : High-pass filter @50Hz, 12 dB/oct. or higher slope.Otherwise as Satellite with subwoofer: Amplifier+DSP to match to subwoofer. High-pass filter @90Hz, 12 dB/oct. or higher slope. Inner thermal protection deviceOur latest content
Check out what's new in our company !
Your Dynamic Snippet will be displayed here... This message is displayed because you did not provide enough options to retrieve its content.
Specifications
| protection | Weatherised |
| color | RAL |
